TECHNICAL SPECIFICATIONS
 Video format
H.264 1280x720 pixels @ 30 fps
 Display resolution
128x128 pixels
 Field of view
67° or 84°
 Lens
Telecentric with 6 elements
 Supported SD card
Up to 128 GB
 Memory capability
1.5 GB (1 hour low quality recording)
2 GB (1 hour medium quality recording)
4 GB (1 hour high quality recording)
 Internal battery
Rechargeable Lithium battery - 1.950 mAh
 Internal battery duration
120 - 150 min of recording
 Battery charge
700 mAh 12 V
 Accelerometer
Three-axial ± 5G
 External power
9-15 V
 Auto Power ON
Yes, if connected to an AiM logger
 Auto Power OFF
Yes
 Auto Start/Stop Recording
Yes
 Usage temperatures
-10°C/+60°C
 Dimensions
87x63x49 mm
 Weight
280 g, battery included
 Waterproof
IP67
IN THE BOX
SmartyCam HD with 67° or 84° lens, 4 GB HC10 SD card, CAN cable or external power cable, Battery charger, USB/AC power adapter, User manual & RaceStudio 3 software freely downloadable from AiM web site. Any microphone cables excluded.
